Description
Professional microphone for clarinet
Nalbantov NCM 622 Wireless set
The NCM 622 line of instrument microphones is the result of more than 45 years of experience in the field by Nalbantov. The microphones produce an extremely clean, soft and natural sound.
The NCM sound is enhanced by the latest technology in Nalbantov NCM 622, which preserves the best aspects and the essential character of the previous models.
With a stylish Black Granite color and blue backlight, NCM 622 complements your instrument. It has a light weight of only 10g (0.35oz) and a special stage-resistant coating.
Like the other microphones in the NCM series, Nalbantov NCM 622 eliminates acoustic feedback by ignoring airborne sounds. It captures the sound in the instrument’s body, instead of the sound in the air.
By being directly connected to the instrument, NCM microphones ensure an equal and powerful sound in any situation. You can enjoy the perfect mobility on stage and a completely different experience when playing wind instruments.
Top reasons to buy Nalbantov NCM 622 Wireless system:
wireless connection
clean, soft and natural sound in any situation
operates completely without acoustic feedback
improved frequency range and dynamic sensitivity
no wind sounds and ultra-low key noise
superb quality and durability
lightweight made from aluminum
easy and fast installation
universal compatibility and perfect mobility on stage
16 wireless channels
At least 60 meter operation distance
Only one AAA 1.5V battery for 8 hours of usage
Package includes:
Carrying case
Nalbantov NCM 622 microphone
Nalbantov NCM W1 wireless system
Premium Grenadilla Clarinet Barrel (you can choose the size from the menu on top)
Connecting cable for the wireless receiver
AC adapter for the wireless system
Mounting Kit (with this kit you can mount the microphone system to your clarinet barrel)
Plastic screw bolt (to use the clarinet barrel without the system)
User’s manual and installation guide
Warranty – 3 years (1 year guarantee plus 2 years when you register the product online)
Specifications:
NCM 622 Microphone
Frequency range: 30Hz – 20kHz
Connection: 3.5mm (1/8”) audio jack
Mode of operation: Ultra Piezo Technology Fourth Generation (UPT IV)
Polar pattern: Omnidirectional
Compatibility: Universal
Balanced input
Effect boxes
Wireless systems
Power requirements: Use with or without phantom power. No need of power supply to use the microphone. It is required only to light the integrated blue LEDs. The provided cable is made to supply power from the source (you should turn on the phantom power on your mixer/system).
Size: 24.5mm (0.96”) H (without thread) x 21mm (0.82”) W
Weight of microphone: Only 10g (0.35oz)
NCM 622 microphone systems are individually tested in seven different steps through the manufacturing process, to ensure superb quality of performance and resistance against air pressure and humidity.
NCM – W1R Receiver
Frequency Preparation – PLL Synthesized Control
Carrier Frequency Range – 502~960 MHz
S/N Ratio – > 105dB
T.H.D – <0.6%@1KHz
Display – LED
Display Contents – Antenna A/B, RF/AF Status
Controls – Power On/Off, Channel Selecting, Audio Level
Audio Output Level – -12dB
AF Output Impedance – 600Ω
Squelch – Pilot Tone, Noise and Mute
Operation Voltage – 9-15 VDC, 200mA
Output Connector – 1 Unbalanced, 6.3mm (1/4”) audio jack
Dimension – 124mm (4.88”) W х 33mm (1.3”) H х 73mm (2.87”) D
NCM – W1 Miniature Transmitter
Frequency Preparation – PLL Synthesized Control
Carrier Frequency Range – 502~960 MHz
RF Outputs – Maximum 10mW
Stability – ±10KHz
Frequency Deviation – ±48KHz
LCD Display – Power On/Off, Low battery, Mute
Controls – Power On/Off, AF Level, Channel Selecting, Mute
Spurious Emissions – <- 50 dBC
Audio Frequency Response – 40~18,000 Hz
Battery – LR03, AAA 1.5V*1
